RAS machines for: Roof and wall profiles

Lübke baumetal: Carefree package

Lübke baumetal GmbH is a full-range supplier of profiles for roofs and facades. Standard profiles as well as highly customized products are the specialty of the company based in Arnsberg, North Rhine-Westphalia. In addition to the first-class products, the success of the company is based on competent customer service and a fast distribution system. The most complex production step is the efficient bending of profiles. For this, Lübke relies on as many as three RAS folding machines: two GIGAbends and one XLTbend with a 45 degree upper beam.
[more]    [Video]

Exceptional profiles for 3D printed house

What has a building created by a 3D printer to do with sheet metal profiles? Well, the flat roof should also be closed and that's where rounded profiles from Metallwelt GmbH & Co. KG come into play. In addition to the fancy work, the Arnsberg-based company uses two RAS FLEXIbend folding machines to bend wall copings and other roof and wall profiles.
[more]    [Video]

machine model: FLEXIbend

Freund Metallverarbeitung: Focussed on specials

What a machine is capable to do is usually listed up in performance features of the technical data. However, what makes it special is when these capabilities are combined with the ingenuity of the machine users. In other words, when users come up with special solutions for their customers using clever sheet metal designs. This is the scenario at Freund Dach Metallverarbeitungs GmbH. The sheet metal specialists from Dortmund, Germany are putting their creative ideas into reality with a RAS FLEXIbend folding machine.
[more]    [Video]

machine model: FLEXIbend

XL-Center at roofer Schwaer

Roofer Johannes Schwaer from the Black Forest area in Germany is a dynamically growing roofing company. The growth does not come by chance. In fact, Johannes Schwär always thinks one step ahead and wants to be prepared with his decisions for current, but also future challenges. The investment in an RAS XL-Center with UpDown bending technology illustrates the company's progressive mindset.

Investment in the future

After the decision to modernize the machinery had been made, the only remaining question for Johannes and Thomas Binder was whether to re-invest in a traditional metal folder with only upward bending. In the end, the two roofing professionals decided in favor of a state-of-the-art RAS XL center with UpDown bending technology. "The XL-Center more than compensates the higher investment costs with its additional benefits," summarize the two entrepreneurs.     [more]  [Video]

Wall coping and clever connector profiles

Begoin GmbH uses the RAS XL-Center UpDown folding center for bending roof and wall profiles . Wall copings, joint connector profiles and a cleverly designed wall connection for floating support of a wall coping. This allows the wall coping to expand and contract in hot and cold conditions.

XL-Center: Bending a roof ridge

When automatically bending a roof ridge profile, the RAS XL-Center UpDown bending center shows all its skills. There are already embosses in the sheet for later fastenings. Therefore, the upper beam must gently clamp the sheet so that the embosses are not damaged during bending. The Bendex software automatically programs the bending sequence based on the drawn profile.

machine model: XL-Center

New business segment with XXL-Center and Bendex

On their homepage, Schütze GmbH reports that they have invested in a slitting line and a state-of-the-art XXL-Center long double folding machine. This allows them to produce and deliver profiles for roofs and walls quicker and more economically. The secret of success is, however, the organization in the background using the Bendex.professional software. Only the combination of machine and software led to this achieved efficiency.

Bending roof tile profiles

Manfred Baldauf and his wife first saw the RAS XL-Center at the DACH+HOLZ (Roof+Wood) show and immediately fell in love with the machine. The roofing and tinsmith company from Doren (Austria) works on both residential housing construction and with commercial developers and builders. The capability to form unique and unusual facades has most impressed Manfred Baldauf and the RAS XL-Center can bend exactly these profiles with whimsical shapes, radii and hems.

Made for speed

In 2014, Feilmeier AG wanted to acquire an additional long bending center with bidirectional bending; they wanted a machine that can bend the metal both up and down without any flipping of the part required. Key to their decision to purchase a RAS XXL-Center was the fully integrated Bendex-Software, which automatically programs the parts. The firm’s owner Ludwig Feilmeier had a clear vision of what he expected from his new machine. The large space in front of the folding beam allows Feilmeier to bend parts that they could not offer before.

Digitizing the Construction Site!

Stefan Bern is a roofing and façade specialist for demanding residential buildings. With a team of 30 employees, the company produces all metal parts in their workshop. Their own skilled workers assemble the profiles on large private properties in the area. With the RAS XL-Center, the company has significantly increased its efficiency and bending speed.

Now also in 8 meter length ...

The well-known Schrag Group is specialized in the production and distribution of roof and wall profiles for industrial buildings. In order to achieve their goals of reliability, speed and quality, the Schrag Group uses several XXL-Center long folding center from RAS which automatically programs the profiles. Technical director Bernd Wurmbach has noted: "If we run a 0.75 mm part 5 meters long with six to seven bends, the XXL-Center is about 50% faster than our other bending machines."

Rolladenkästen mit Doppelfalz

The video shows how the RAS XL-Center automatically programs and folds a roller shutter box for the roof and wall industry. The special feature here: For stiffening the outer edge of the profile the XL-Center first bends a hem and then on double material.

machine model: XL-Center

From YouTube to a finished part

When Carl Schmidt began looking for a new metal folding machine to produce profiles for commercial construction, he took an unusual route. Instead of visiting trade shows or different manufacturers, he started watching YouTube clips of the different manufacturers. He was so impressed by the RAS XL-Center that he decided to place an order without ever seeing the machine live. What might seem to some like a rushed action was, in reality, carefully thought through.

Quick and accurate

In November 2002 FN Profilblech Center GmbH from Bad Rappenau, Germany, installed a RAS XXL-Center. Today the specialist for folded roof and wall parts cannot imagine how they were able to run their business without the high-performing long folding center. What took three shifts on a press and a traditional long folder before, is now completed in one and a half shifts on the XXL-Center.

Bending a complex wall profile

The video shown how the RAS XXL-Center long folding center bends a wall profile up and down. The tables automatically pull-in the blank and reference it. This profile also shows a combination of automated and manual sequences.

machine model: XXL-Center

XXL-Center at H&H Architectural Metals

Jim Huff, owner of H&H Architectural Metals from Denver proudly says: "In the past we needed 20 minutes with 2 people to bend a complicated gutter. With the RAS XXL-Center we run 2 gutters at a time in 2 1/2 minutes with a single person." Machine operator Kevin pulls two metal blanks from the side onto the  machine's sheet support tables. The XXL-Center automatically squares the blanks and runs the parts completely automated. Jim Huff says with a smile: "35 years ago, my wife Kathy and I founded H&H Architectural Metals with $ 6 and 38 cents starting capital." Today the company operates in their own 5500 sqm building with the latest machinery equipment. The succession is also secured by son Chad Huff.

Metal fabrication with up-down bending

Roofer Leib reports on their Website: "As a result of the growing demands of modern architecture, ever more complex metal profiles are required. We can produce them now efficiently and precisely by the purchase of a new XL bending center from RAS. The required profiles can be designed directly in the office and sent to the machine. The machine geometry allows the metal to be folded in two directions, which saves expensive material handling time."

XX-fast with XXL-Center

Since March 2002 Rudolf Wiegmann Umformtechnik from Bersenbrück in Germany
have produced folded profiles for roof and wall with an XXL-Center from RAS Reinhardt Maschinenbau GmbH. The sheet metal specialist processes 2500 tons of coil material and 200 tons of blanks per year. A well equipped steel and aluminum warehouse, fast and precise production, as well as their own assembly company made the Wiegmann Group a respected and reliable partner in the industrial building industry.

Speedy production

The Altvater GmbH is specialized in roofing and architectural components. Simon and Altvater follow a simple rule: "Lastest machine technology allows producing more profitable." Shortly after they have received the FLEXIbend, Altvater received a big order for aluminum parts. The calculation was based on an older long folding machine. The FLEXIbend however, with a single operator bends almost twice as fast. Therefore, they decided bending the parts only in lengths of 3000 mm. Altvater smiles: "We have made a good profit with this order."

machine model: FLEXIbend

Tread Plate Folding

Tread plates are often used in the automotive industry as non-slip loading ramps on trucks, for tool boxes on pick-ups and for emergency vehicles and fire trucks. Tread is also common in the machine tool design. In industrial building construction, aluminum and steel tread plates are used for stair step designs. RAS folding systems can fold these often large sized blanks precisely and accurately with little effort.

machine model: FLEXIbend
